Kamailio Bytes – Transaction Module

Kamailio, VoIP, , , , , ,

We talked a little about the Transaction module and using it for Transaction Stateful SIP Proxy, but it’s worth knowing a bit more about the Transaction Module and the powerful functions it offers.

So today I’ll cover some cool functionality TM offers!

Different Reply Routes

By calling the t_on_reply(); we can specify the reply route to be used for replies in this transaction.

route[RELAY]{

        #Use reply route "OurReplyRoute" for responses for this transaction
        t_on_reply("OurReplyRoute");

        #Relay (aka Forward) the request
        t_relay_to_udp("192.168.3.118", "5060");

}

onreply_route[OurReplyRoute] {
        #On replies from route[RELAY]

        #Check our AVP we set in the initial request
        xlog("for $rs response the value of AVP \"state_test_var\" is $avp(state_test_var) ");

        #Append a header so we can see this was proxied in the SIP capture
        append_hf("X-Proxied: For the reply\r\n");

}

Any responses from the route[RELAY] routing block will go to onreply_route[OurReplyRoute], the beauty of this is it allows you to have multiple reply routes each with their own logic. For example for a call leg to a carrier you may want to preserve CLI, but for a call leg to a customer you may wish to restrict it if that’s the option the user has selected, and you can make these changes / modifications in the reply messages.

Failure Routes

Failure routes allow the transaction module to know to try again if a call fails, for example if no response is received from the destination, send it to a different destination, like a backup.

route[RELAY]{

        #Use reply route "OurReplyRoute" for responses for this transaction
        t_on_reply("OurReplyRoute");
        t_on_failure("OurFailureRoute");
        #Relay (aka Forward) the request
        t_relay_to_udp("192.168.1.118", "5060");

}

failure_route[OurFailureRoute]{
        xlog("At failure route");
        t_reply("500", "Remote end never got back to us");
        exit;
}

We can build upon this, and try a different destination if the first one fails:

request_route {

        #Enable record_routing so we see the BYE / Re-INVITE etc
        record_route();

        #Handle Registrations in a dumb way so they don't messy our tests
        if(is_method("REGISTER")){
                sl_reply("200", "ok");
                exit;
        }



                 #Append a header so we can see this was proxied in the SIP capture
                append_hf("X-Proxied: You betcha\r\n");

        if(is_method("INVITE")){
                        #Createa  new AVP called "state_test_var" and set the value to "I remember"
                        $avp(state_test_var) = "I remember";
        }
                #Let syslog know we've set the value and check it
                xlog("for $rm the value of AVP \"state_test_var\" is $avp(state_test_var) ");

                #Send to route[RELAY] routing block
                rewritehostport("nonexistentdomain.com");
                route(RELAY);

}

route[RELAY]{

        #Use reply route "OurReplyRoute" for responses for this transaction
        t_on_reply("OurReplyRoute");
        t_on_failure("OurFailureRoute");
        #Relay (aka Forward) the request
        t_relay();
}

failure_route[OurFailureRoute]{
        xlog("At failure route");
        #t_reply("500", "Remote end never got back to us");

                rewritehostport("192.168.3.118");
                append_branch();
                t_relay();

}

onreply_route[OurReplyRoute] {
        #On replies from route[RELAY]

        #Check our AVP we set in the initial request
        xlog("for $rs response the value of AVP \"state_test_var\" is $avp(state_test_var) ");

        #Append a header so we can see this was proxied in the SIP capture
        append_hf("X-Proxied: For the reply\r\n");

}

One thing to keep in mind is that there’s lots of definitions of failure, for example if you are sending a call to a carrier and get a 404 response back, you probably want to relay that through to the end user, because that destination isn’t there.

But if you get back a 5xx series response you may consider that to be a failure and select the next carrier for example.

Different conditions / requirements have different definitions of “failures” and so there’s a lot to think about when implementing this, along with timeouts for no replies, TCP session management, etc.

Parallel Forking the Call to Multiple Destinations

Parallel Forking is a fancy way of saying ring multiple destinations at the same time.

/* Main SIP request routing logic
 * - processing of any incoming SIP request starts with this route
 * - note: this is the same as route { ... } */
request_route {

        #Enable record_routing so we see the BYE / Re-INVITE etc
        record_route();

        #Handle Registrations in a dumb way so they don't messy our tests
        if(is_method("REGISTER")){
                sl_reply("200", "ok");
                exit;
        }



                 #Append a header so we can see this was proxied in the SIP capture
                append_hf("X-Proxied: You betcha\r\n");

        if(is_method("INVITE")){
                        #Createa  new AVP called "state_test_var" and set the value to "I remember"
                        $avp(state_test_var) = "I remember";
        }
                #Let syslog know we've set the value and check it
                xlog("for $rm the value of AVP \"state_test_var\" is $avp(state_test_var) ");

                #Send to route[RELAY] routing block
                route(RELAY);

}

route[RELAY]{

        #Use reply route "OurReplyRoute" for responses for this transaction
        t_on_reply("OurReplyRoute");

        #Append branches for each destination we want to forward to
        append_branch("sip:[email protected]");
        append_branch("sip:[email protected]");
        append_branch("sip:[email protected]");

        t_on_failure("OurFailureRoute");
        #Relay (aka Forward) the request
        t_relay();
}

failure_route[OurFailureRoute]{
        xlog("At failure route");
        t_reply("500", "All those destinations failed us");

}

onreply_route[OurReplyRoute] {
        #On replies from route[RELAY]

        #Check our AVP we set in the initial request
        xlog("for $rs response the value of AVP \"state_test_var\" is $avp(state_test_var) ");

        #Append a header so we can see this was proxied in the SIP capture
        append_hf("X-Proxied: For the reply\r\n");

}

Bit of a mess but here we see the initial INVITE being branched to the 3 destinations at the same time (Parallel forking)

Serial Forking / Sequential Forking the calls to Multiple Destinations one after the Other

This could be used to try a series of weighted destinations and only try the next if the preceding one fails:

/* Main SIP request routing logic
 * - processing of any incoming SIP request starts with this route
 * - note: this is the same as route { ... } */
request_route {

        #Enable record_routing so we see the BYE / Re-INVITE etc
        record_route();


        #Send to route[RELAY] routing block
        route(RELAY);

}

route[RELAY]{

        #Use reply route "OurReplyRoute" for responses for this transaction
        t_on_reply("OurReplyRoute");

        append_branch("sip:[email protected]", "0.3");
        append_branch("sip:[email protected]", "0.2");
        append_branch("sip:[email protected]", "0.1");

        t_load_contacts();

        t_next_contacts();

        t_on_failure("OurFailureRoute");
        #Relay (aka Forward) the request
        t_relay();
        break;
}

failure_route[OurFailureRoute]{

        xlog("At failure route - Trying next destination");
        t_on_failure("OurFailureRoute");
        t_relay();


}

onreply_route[OurReplyRoute] {
        #On replies from route[RELAY]
        #Append a header so we can see this was proxied in the SIP capture
        append_hf("X-Proxied: For the reply\r\n");

}

Again this will try each destination, but one after the other based on the weight we added to each destination in the append_branch()

Here we see each destination being tried sequentially

Transaction Stateful Proxy with Kamailio

Kamailio, VoIP, , , , , ,

We covered the 3 different types of SIP Proxy, Stateless, Transaction Stateful and Dialog Stateful.

It’s probably worth going back to have a read over the description of the types of proxy and have a read over the whole Stateless proxy we implemented in Kamailio, before we get started on Stateful proxies, because we’ll be carrying on from what we started there.

The Setup

The 3 different proxies all do the same thing, they all relay SIP messages, so we need a way to determine what state has been saved.

To do this we’ll create a variable (actually an AVP) in the initial request (in our example it’ll be an INVITE), and we’ll reference it when handling a response to make sure we’ve got transactional state.

We’ll also try and reference it in the BYE message, which will fail, as we’re only creating a Transaction Stateful proxy, and the BYE isn’t part of the transaction, but in order to see the BYE we’ll need to enable Record Routing.

Stateless Proof

Before we add any state, let’s create a working stateless proxy, and add see how it doesn’t remember:

####### Routing Logic ########


/* Main SIP request routing logic
 * - processing of any incoming SIP request starts with this route
 * - note: this is the same as route { ... } */
request_route {

        #Enable record_routing so we see the BYE / Re-INVITE etc
        record_route();

        #Handle Registrations in a dumb way so they don't messy our tests
        if(is_method("REGISTER")){
                sl_reply("200", "ok");
                exit;
        }



                 #Append a header so we can see this was proxied in the SIP capture
                append_hf("X-Proxied: You betcha\r\n");

        if(is_method("INVITE")){
                        #Createa  new AVP called "state_test_var" and set the value to "I remember"
                        $avp(state_test_var) = "I remember";
        }
                #Let syslog know we've set the value and check it
                xlog("for $rm the value of AVP \"state_test_var\" is $avp(state_test_var) ");

                #Forard to new IP
                forward("192.168.3.118");



}

onreply_route{
        #Check our AVP we set in the initial request
        xlog("for $rs response the value of AVP \"state_test_var\" is $avp(state_test_var) ");

        #Append a header so we can see this was proxied in the SIP capture
        append_hf("X-Proxied: For the reply\r\n");
}

Now when we run this and call from any phone other than 192.168.3.118, the SIP INVITE will hit the Proxy, and be forwarded to 192.168.3.118.

Syslog will show the INVITE and us setting the var, but for the replies, the value of AVP $avp(state_test_var) won’t be set, as it’s stateless.

Let’s take a look:

kamailio[2577]: {1 1 INVITE [email protected]} ERROR: : for INVITE the value of AVP "state_test_var" is I remember
kamailio[2575]: {2 1 INVITE [email protected]} ERROR: <script>: for 100 response the value of AVP "state_test_var" is <null>
kamailio[2576]: {2 1 INVITE [email protected]} ERROR: <script>: for 180 response the value of AVP "state_test_var" is <null>
kamailio[2579]: {2 1 INVITE [email protected]} ERROR: <script>: for 200 response the value of AVP "state_test_var" is <null>
kamailio[2580]: {1 1 ACK [email protected]} ERROR: <script>: for ACK the value of AVP "state_test_var" is <null>
kamailio[2581]: {1 2 BYE [email protected]} ERROR: <script>: for BYE the value of AVP "state_test_var" is <null>

We can see after the initial INVITE none of the subsequent replies knew the value of our $avp(state_test_var), so we know the proxy is at this stage – Stateless.

I’ve put a copy of this code on GitHub for you to replicate yourself.

Adding State

Doing the heavy lifting of our state management is the Transaction Module (aka TM). The Transaction Module deserves a post of it’s own (and it’ll get one).

We’ll load the TM module (loadmodule “tm.so”) and use the t_relay() function instead of the forward() function.

But we’ll need to do a bit of setup around this, we’ll need to create a new route block to call t_relay() from (It’s finicky as to where it can be called from), and we’ll need to create a new reply_route{} to manage the response for this particular dialog.

Let’s take a look at the code:

####### Routing Logic ########


/* Main SIP request routing logic
 * - processing of any incoming SIP request starts with this route
 * - note: this is the same as route { ... } */
request_route {

        #Enable record_routing so we see the BYE / Re-INVITE etc
        record_route();

        #Handle Registrations in a dumb way so they don't messy our tests
        if(is_method("REGISTER")){
                sl_reply("200", "ok");
                exit;
        }



                 #Append a header so we can see this was proxied in the SIP capture
                append_hf("X-Proxied: You betcha\r\n");

        if(is_method("INVITE")){
                        #Createa  new AVP called "state_test_var" and set the value to "I remember"
                        $avp(state_test_var) = "I remember";
        }
                #Let syslog know we've set the value and check it
                xlog("for $rm the value of AVP \"state_test_var\" is $avp(state_test_var) ");

                #Send to route[RELAY] routing block
                route(RELAY);

}

route[RELAY]{

        #Use reply route "OurReplyRoute" for responses for this transaction
        t_on_reply("OurReplyRoute");

        #Relay (aka Forward) the request
        t_relay_to_udp("192.168.3.118", "5060");

}

onreply_route[OurReplyRoute] {
        #On replies from route[RELAY]

        #Check our AVP we set in the initial request
        xlog("for $rs response the value of AVP \"state_test_var\" is $avp(state_test_var) ");

        #Append a header so we can see this was proxied in the SIP capture
        append_hf("X-Proxied: For the reply\r\n");

}

So unlike before where we just called forward(); to forward the traffic we’re now calling in a routing block called RELAY.

Inside route[RELAY] we set the routing block that will be used to manage replies for this particular transaction, and then call t_relay_to_udp() to relay the request.

We renamed our onreply_route to onreply_route[OurReplyRoute], as specified in the route[RELAY].

So now let’s make a call (INVITE) and see how it looks in the log:

kamailio[5008]: {1 1 INVITE [email protected]} ERROR: : for INVITE the value of AVP "state_test_var" is I remember
kamailio[5005]: {2 1 INVITE [email protected]} ERROR: <script>: for 100 response the value of AVP "state_test_var" is I remember
kamailio[5009]: {2 1 INVITE [email protected]} ERROR: <script>: for 180 response the value of AVP "state_test_var" is I remember
kamailio[5011]: {2 1 INVITE [email protected]} ERROR: <script>: for 200 response the value of AVP "state_test_var" is I remember
kamailio[5010]: {1 1 ACK [email protected]} ERROR: <script>: for ACK the value of AVP "state_test_var" is <null>
kamailio[5004]: {1 2 BYE [email protected]} ERROR: <script>: for BYE the value of AVP "state_test_var" is <null>
kamailio[5007]: {2 2 BYE [email protected]} ERROR: <script>: for 200 response the value of AVP "state_test_var" is <null>

Here we can see for the INVITE, the 100 TRYING, 180 RINGING and 200 OK responses, state was maintained as the variable we set in the INVITE we were able to reference again.

(The subsequent BYE didn’t get state maintained because it’s not part of the transaction.)

And that’s it.

Here’s a copy of my running code on GitHub.

Hopefully now you’ve got an idea of the basics of how to implement a transaction stateful application in Kamailio.

Stateless, Stateful, Dialog Stateful and Transaction Stateful SIP Proxies

RFCs & Standards, VoIP, , , , ,

If you’ve ever phoned a big company like a government agency or an ISP to get something resolved, and been transferred between person to person, having to start again explaining the problem to each of them, then you know how frustrating this can be.

If they stored information about your call that they could bring up later during the call, it’d make your call better.

If the big company, started keeping a record of the call that could be referenced as the call progresses, they’d be storing state for that call.

Let’s build on this a bit more,

You phone Big Company again, the receptionist answers and says “Thank you for calling Big Company, how many I direct your call?”, and you ask to speak to John Smith.

The receptionist puts you through to John Smith, who’s not at his desk and has setup a forward on his phone to send all his calls to reception, so you ring back at reception.

A stateful receptionist would say “Hello again, it seems John Smith isn’t at his desk, would you like me to take a message?”.

A stateless receptionist would say “Thank you for calling Big Company, how many I direct your call?”, and you’d start all over again.

Our stateful receptionist remembered something about our call, they remembered they’d spoken to you, remembered who you were, that you were trying to get to John Smith.

While our stateless receptionist remembered nothing and treated this like a new call.

In SIP, state is simply remembering something about that particular session (series of SIP messages).

SIP State just means bits of information related to the session.

Stateless SIP Proxy

A Stateless SIP proxy doesn’t remember anything about the messages (sessions), no state information is kept. As soon as the proxy forwards the message, it forgets all about it, like our receptionist who just forwards the call and doesn’t remember anything.

Going back to our Big Company example, as you can imagine, this is much more scaleable, you can have a pool of stateless receptionists, none of whom know who you are if you speak to them again, but they’re a lot more efficient because they don’t need to remember any state information, and they can quickly do their thing without looking stuff up or memorising it.

The same is true of a Stateless SIP proxy.

Stateless proxies are commonly used for load balancing, where you want to just forward the traffic to another destination (maybe using the Dispatcher module) and don’t need to remember anything about that session.

It sounds obvious, but because a Stateless SIP proxy it stateless it doesn’t store state, but that also means it doesn’t need to lookup state information or write it back, making it much faster and generally able to handle larger call loads than a stateful equivalent.

Dialog Stateful SIP Proxy

A dialog stateful proxy keeps state information for the duration of that session (dialog).

By dialog we mean for the entire duration on the call/session (called a dialog) from beginning to end, INVITE to BYE.

While this takes more resources, it means we can do some more advanced functions.

For example if we want to charge based on the length of a call/session, we’d need to store state information, like the Call-ID, the start and end time of the call. We can only do this with a stateful proxy, as a stateless proxy wouldn’t know what time the call started.

Also if we wanted to know if a user was on a call or not, a Dialog Stateful proxy knows there’s been a 200 OK, but no Bye yet, so knows if a user is on a call or not, this is useful for presence. We could tie this in with a NOTIFY so other users could know their status.

A Dialog Stateful Proxy is the most resource intensive, as it needs to store state for the duration of the session.

Transaction Stateful SIP Proxy

A transactional proxy keeps state until a final response is received, and then forgets the state information after the final response.

A Transaction Stateful proxy stores state from the initial INVITE until a 200 OK is received. As soon as the session is setup it forgets everything. This means we won’t have any state information when the BYE is eventually received.

While this means we won’t be able to do the same features as the Dialog Stateful Proxy, but you’ll find that most of the time you can get away with just using Transaction Stateful proxies, which are less resource intensive.

For example if we want to send a call to multiple carriers and wait for a successful response before connecting it to the UA, a Transactional proxy would do the trick, with no need to go down the Dialog Stateful path, as we only need to keep state until a session is successfully setup.

For the most part, SIP is focused on setting up sessions, and so is a Transaction Stateful Proxy.

Typical Use Cases

StatelesssDialog StatefulTransaction Stateful
Load balancer,
Redirection server,
Manipulate headers,
Call charging,
CDR generation,
User status (Knows if on call)
All features of transaction stateful		Dispatch to destinations until successful
Call forward on Busy / No Answer
SIP Registrar
Call forking
