Kamailio Bytes – Working with Redis

I’ve become a big fan of Redis, and recently I had a need to integrate it into Kamailio.

There are two modules for integrating Kamailio and Redis, each have different functionalities:

  • db_redis is used when you want to use Redis in lieu of MySQL, PostGres, etc, as the database backend, this would be useful for services like usrloc. Not all queries / function calls are supported, but can be used as a drop-in replacement for a lot of modules that need database connectivity.
  • ndb_redis exposes Redis functions from the Kamailio config file, in a much more generic way. That’s what we’ll be looking at today.

The setup of the module is nice and simple, we load the module and then define the connection to the Redis server:

import "ndb_redis.so"
modparam("ndb_redis", "server", "name=MyRedisServer;addr=;port=6379")

With the above we’ve created a connection to the Redis server at, and it’s called MyRedisServer.

You can define multiple connections to multiple Redis servers, just give each one a different name to reference.

Now if we want to write some data to Redis (SET) we can do it from within the dialplan with:

redis_cmd("MyRedisServer", "SET foo bar", "r");

We can then get this data back with:

#Get value of key "foo" from Redis
redis_cmd("MyRedisServer", "GET foo", "r");
#Set avp "foo_value" to output from Redis
$avp(foo_value) = $redis(r=>value);
#Print out value of avp "foo_value" to syslog
xlog("Value of foo is:  $avp(foo_value))

At the same time, we can view this data in Redis directly by running:

nick@oldfaithful:~$ redis-cli GET foo

Likewise we can set the value of keys and the keys themselves from AVPs from within Kamailio:

#Set the Redis Key to be the Received IP, with the value set to the value of the AVP "youravp"
redis_cmd("MyRedisServer", "SET $ct $avp(youravp)", "r");

All of the Redis functions are exposed through this mechanism, not just get and set, for example we can set the TTL so a record deletes after a set period of time:

#Set key with value of the received IP to expire after 120 seconds
redis_cmd("MyRedisServer", "EXPIRE $ct 120", "r");

I recently used Redis for a distributed flooding prevention mechanism, where the Subscriber’s received IP is used as the key in Redis and the value set to the number of failed auth attempts that subscriber has had, by using Redis we’re able to use the same mechanism across different platforms and easily administer it.

GIF showing using Redis-CLI to get a value

Adding SNMP to anything with Redis and Python

I’ve been adding SNMP support to an open source project I’ve been working on (PyHSS) to generate metrics / performance statistics from it, and this meant staring down SNMP again, but this time I’ve come up with a novel way to handle SNMP, that made it much less painful that normal.

The requirement was simple enough, I already had a piece of software I’d written in Python, but I had a need to add an SNMP server to get information about that bit of software.

For a little more detail – PyHSS handles Device Watchdog Requests already, but I needed a count of how many it had handled, made accessible via SNMP. So inside the logic that does this I just increment a counter in Redis;

#Device Watchdog Answer
    def Answer_280(self, packet_vars, avps):

In the code example above I just add 1 (increment) the Redis key ‘Answer_280_attempt_count’.

The beauty is that that this required minimal changes to the rest of my code – I just sprinkled in these statements to increment Redis keys throughout my code.

Now when that existing function is run, the Redis key “Answer_280_attempt_count” is incremented.

So I ran my software and the function I just added the increment to was called a few times, so I jumped into redis-cli to check on the values;

GIF showing using Redis-CLI to get a value

And just like that we’ve done all the heavy lifting to add SNMP to our software.

For anything else we want counters on, add the increment to your code to store a counter in Redis with that information.

So next up we need to expose our Redis keys via SNMP,

For this, I took a simple SNMP server example from Stackoverflow, to set the output of a MIB tree, and simply bolted in getting a bit of data from, code below:

#Pulled from https://stackoverflow.com/questions/58909285/how-to-add-variable-in-the-mib-tree

from pysnmp.entity import engine, config
from pysnmp.entity.rfc3413 import cmdrsp, context
from pysnmp.carrier.asyncore.dgram import udp
from pysnmp.smi import instrum, builder
from pysnmp.proto.api import v2c
import datetime
import redis

import redis
redis_store = redis.Redis(host='localhost', port=6379, db=0)
# Create SNMP engine
snmpEngine = engine.SnmpEngine()

# Transport setup

# UDP over IPv4
    udp.UdpTransport().openServerMode(('', 1161))

# SNMPv3/USM setup

# user: usr-md5-none, auth: MD5, priv NONE
    snmpEngine, 'usr-md5-none',
    config.usmHMACMD5AuthProtocol, 'authkey1'
# Allow full MIB access for each user at VACM
config.addVacmUser(snmpEngine, 3, 'usr-md5-none', 'authNoPriv', (1, 3, 6, 1, 2, 1), (1, 3, 6, 1, 2, 1))

# SNMPv2c setup

# SecurityName <-> CommunityName mapping.
config.addV1System(snmpEngine, 'my-area', 'public')

# Allow full MIB access for this user / securityModels at VACM
config.addVacmUser(snmpEngine, 2, 'my-area', 'noAuthNoPriv', (1, 3, 6, 1, 2, 1), (1, 3, 6, 1, 2, 1))

# Get default SNMP context this SNMP engine serves
snmpContext = context.SnmpContext(snmpEngine)

# Create an SNMP context with default ContextEngineId (same as SNMP engine ID)
snmpContext = context.SnmpContext(snmpEngine)

# Create multiple independent trees of MIB managed objects (empty so far)
mibTreeA = instrum.MibInstrumController(builder.MibBuilder())
mibTreeB = instrum.MibInstrumController(builder.MibBuilder())

# Register MIB trees at distinct SNMP Context names
snmpContext.registerContextName(v2c.OctetString('context-a'), mibTreeA)
snmpContext.registerContextName(v2c.OctetString('context-b'), mibTreeB)

mibBuilder = snmpContext.getMibInstrum().getMibBuilder()

MibScalar, MibScalarInstance = mibBuilder.importSymbols(
    'SNMPv2-SMI', 'MibScalar', 'MibScalarInstance'
class MyStaticMibScalarInstance(MibScalarInstance):
    def getValue(self, name, idx):
        currentDT = datetime.datetime.now()
        return self.getSyntax().clone(
            'Hello World!! It\'s currently: ' + str(currentDT)

class AnotherStaticMibScalarInstance(MibScalarInstance):
    def getValue(self, name, idx):
        return self.getSyntax().clone('Ahoy hoy?')

class Answer_280_attempt_count(MibScalarInstance):
    def getValue(self, name, idx):
        return self.getSyntax().clone(redis_store.get('Answer_280_attempt_count'))

    '__MY_MIB', MibScalar((1, 3, 6, 1, 2, 1, 1, 1), v2c.OctetString()),
    MyStaticMibScalarInstance((1, 3, 6, 1, 2, 1, 1, 1), (0,), v2c.OctetString()),
    AnotherStaticMibScalarInstance((1, 3, 6, 1, 2, 1, 1, 1), (0,1), v2c.OctetString()),
    Answer_280_attempt_count((1, 3, 6, 1, 2, 1, 1, 1), (0,2), v2c.Integer32())

# Register SNMP Applications at the SNMP engine for particular SNMP context
cmdrsp.GetCommandResponder(snmpEngine, snmpContext)
cmdrsp.SetCommandResponder(snmpEngine, snmpContext)
cmdrsp.NextCommandResponder(snmpEngine, snmpContext)
cmdrsp.BulkCommandResponder(snmpEngine, snmpContext)

# Register an imaginary never-ending job to keep I/O dispatcher running forever

# Run I/O dispatcher which would receive queries and send responses


While PySNMP can be a bit much to wrap your head around, all you need to know:

V2 community string set in:

config.addV1System(snmpEngine, 'my-area', 'public')

Create an additional class from the template below for each of your Redis keys you wish to expose;

class something_else_from_Redis(MibScalarInstance):
    def getValue(self, name, idx):
        return self.getSyntax().clone(redis_store.get('something_else_from_Redis'))

Renaming the class and replacing the redis_store.get() value with the Redis key you want to pull,

And finally inside mibBuilder.exportSymbols() add each of the new classes you added and the OID for each;

    Answer_280_attempt_count((1, 3, 6, 1, 2, 1, 1, 1), (0,2), v2c.Integer32())
    something_else_from_Redis((1, 3, 6, 1, 2, 1, 1, 1), (0,3), v2c.Integer32())

Then when you run it, presto, you’re exposing that data via SNMP.

You can verify it through SNMP walk or start integrating it into your NMS, in the above example OID, contains the value of Answer_280_attempt_count from Redis, and with that, you’re exposing info via SNMP, all while not really having to think about SNMP.

*Ok, you still have to sort which OIDs you assign for what, but you get the idea.
